Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights

China Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights supplier
Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights supplier Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights supplier

Large Image :  Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights

Product Details:

Place of Origin: Guangdong
Brand Name: NorthTime
Certification: CE ROHS IP65
Model Number: IN-112C

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: 1Set/Carton, Carton Size:46x35x15 cm
Delivery Time: 10-15 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 7000 Set /Month
Contact Now
Detailed Product Description
Solar Panel: 18V 18W Monocrystalline Silicon (Germany Solarworld) Case Material: Aluminum Alloy
LED Light: USA Bridgelux LED With High Brightness Lumens: 1200-1300 LM
Battery: Lithium Battery 12V 7AH Mounting Height: 3-4 M
Discharge Time: 4 Rainy Days Charge Time: 6-7 Hours With Sunshine
Working Mode: Infrared PIR Motion Sensor & Light Control Working Temperature: -30℃~+60℃
Warranty: 3 Years Smart Function: Phone App Control Through Bluetooth

Anti-rust LED Solar Garden Lights Home Lighting System with 3 Years Warranty





1. Product Description:



Yigang All-in-One Solar LED Street Light offers high brightness and compact, aesthetic design with a longer life (lithium-ion battery). With smart PIR sensors that modify lighting according to human presence, this is truly the light of the future. More over with the solar panel, LED lights and battery as one single fixture, this solar street light is an all encompassing light like none other. The path to the future is bright, with Yigang All-in-One. These lights can be used mainly for urban roads, residential layouts, parks, public gardens, highways, industrial and commercial purpose, etc.





2. Main Components of All in One / Integrated Solar Street Light:



1) Aluminum Alloy body

Patents design, utility model patents, anti-typhoon, anti-wind, anti-corrosion, waterproof grade IP65;
Installation angle adjustable and available for different road.

2) LED Chips

High transmittance of optical glass, no dark area on the road.
Unique phosphor formulation, advanced technology, high brightness imported United States brand Brigelux LED chips, the entire lighting efficiency > 100 lm/W;


3) Controller

Digital intelligent MPPT control systems, non-electrolytic capacitor design, the lifespan up to 10 years.
Night intelligent dimming system, late at night can be a half-power operation.

4) Lithium Battery

We use the lithium iron phosphate battery which is environmentally friendly. It is inside the product to avoid being stolen. Its lifespan is more than 5 years.

5)
Solar Panel

We use Germany Solarword efficiency mono crystalline silicon solar panel, its photoelectric conversion efficiency can reach 20%. Another kind of solar panel is United States brand Sunpower efficiency mono crystalline silicon, its efficiency can reach 22%. Lifespan is 25 years for solar panel.



Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights



3. Working Principle:



1. Automatic light sensor

2. Human body induction ( PIR Infrared Motion Sensor )

3. Automatic recharge at day, automatic lights at night





4. Specification for 12W LED Solar Street Light:



Output Power: 12W





















6500-7000K(CW)

Input Voltage: DC12V
Solar Panel: 18V 18W Monocrystalline silicon (Germany Solarworld)
Solar Panel Lifetime: 25 years
Battery Type: 12V 7AH Lithium Battery (LiFePO4)
Battery Lifetime: 5 years
Source type: USA Bridgelux LED with High Brightness
Luminous Flux: 1200-1300LM
Luminous Efficiency: 115LM/W
IP Rating: IP65
Mounting Height: 3-4 Meters
Working Mode: PIR Motion Sensor & Light Control
Body Material: Aluminum Alloy
Charge Time: 7 hours
Lighting Time: 4 rainy days
Product Size: 35*31*4.5 cm
Working temperature: -30ºC~+50ºC
Product Warranty: 3 Years
Application : Gardens, Streets, residential, industrial zone roads, square and park, school, campus, farm, villas, etc.





5. Application:



All-in-one solar street lights are excellent to provide energy saving and long-lasting illuminations for any outdoor areas, such as school roads, pathways, walkways, village paths, secondary ways, motorways, mine areas, residential areas, courtyards, gardens, parks, gardens, parking lots, streets, gas station and rural areas etc.



Anti-rust LED Solar Garden Lights Home Lighting System , Solar Powered Road Lights



6. Installation:


It is very easy to install the integrated solar LED street light, just to lay the foundation of a straight bar, then it can be installed, usually two workers can complete the installation only with a wrench in 5-8 minutes, no need using heavy equipment or tools.





7. About Integrated Solar Street Light:



1.Why Choose Solar Energy?

It's renewable energy, environmental friendly and make our world better.

2.The Working Principle of Solar Street Light

Set the lights under sun shine, charged by the sunshine during the daytime and stored the power in batteries for lighting in nightime.

3.Advantages

Easy install, security, no cost on energy, long lifespan.
