100W Outdoor Optial Lens Grade A+ Solar Cell Integrated led light Solar Street Light

Place of Origin CHINA
Brand Name Coursertech
Certification 202130742917.X
Model Number BCT-OLF-100W
Minimum Order Quantity 100
Price 120USD
Packaging Details CARTON
Delivery Time 30 work days
Payment Terms T/T
Supply Ability 20000 sets a month
Product Details
Product Name SOLAR LED STREET LIGHT Material Iron And Aluminium
Light Source High Lumen Led Smd Installation Height 8-10M
Installation Distance 35-45M Color Temperature 3000-6500k
Control Switch Solar Panel Charging Time (under Sunlight) 8 Hours
Solar Panel Charging Time (rainy Day) 3-5days Daily Working Hours ≥12hours
Storage Temperature 0-55°C Working Temperature ≤90RH%
Waterproof Level IP65 Product Size 1417*390*273mm ( Customization )
High Light

IP65 Integrated Led Street Light


100W Integrated Solar Street Light


IP65 Integrated Solar Street Light

Leave a Message
Product Description

100W PC Outdoor Optial Lens Grade A+ Solar Cell Integrated Solar Street Light


Integrated Led Street Light Factory Manufacturer Colorful



The all-in-one solar street light is converted into electrical energy by the solar panel, and then charges the lithium battery in the all-in-one solar street light. During the day, even on cloudy days, this solar generator (solar panel) collects and stores the required energy, and automatically supplies power to the LED lights of the integrated solar street light at night to achieve nighttime lighting. At the same time, the integrated solar street light has, PIR human body The induction function can control the working mode of the infrared sensor of the intelligent human body at night, 100% bright when there are people, and automatically change to 1/3 of the brightness after a certain time delay when no one is there, saving more energy intelligently. At the same time, as an "inexhaustible" safe and environmentally friendly new energy source, solar energy plays an important role in integrated solar street lights.



led all in one solar street light parameters:



Parameter BCT-OLF-80W BCT-OLF-100W
Solar panel (single crystal) 80W 100W
Lithium iron phosphate battery (built-in) 3.2V/100(±5)Ah 3.2V/100(±5)Ah
Main light source (main light source) 6000lm 7000lm
Light source (secondary light source)   1000lm
Lighting time
Installation height 8-10m 8-10m
Installation distance 35-45m 35-45m
CCT 3000-6500K 3000-6500K
Pole diameter 60-65mm 60-65mm
Solar panel charging time(Under strong sunlight) 8hours 8hours
Solar panel charging time(rain) 3-5days 3-5days
Day working time ≥12hours ≥12hours
Storage temperature 0-55℃ 0-55℃
Working temperature ≤90RH% ≤90RH%
Waterproof grade IP65 IP65
Product size 1047*390*273mm 1417*390*273mm


1. Solar Panel:mono or poly-crystalline,20years life.
2. Battery:maintenance-free lead-acid or gel battery,over charge and over discharge protection,7-8years life.
3. Controller:MPPT charging mode,switch mode,switch on/off by light and time,5years life.
4. LED lamp:imported LED chip,high efficiency,more than 80000hours life.
5. Pole:zinc-plated steel pole and painting color of your choice,with the whole kit of stainless steel fasteners,20 years life.
6. Working Hours:10-12hours/night,normal lighting 360days/year.
7. Environmental Temperature:-30℃~+60℃
8. Wind Resistance:more than 150km/h
9. Dustproof andwaterproof.
10. Height:6m-12m.
(Custom-made specific requirements!)
