30w 100w All In One Solar Street Light 100-265V PF0.9 integrated solar street light
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Integrated Led Street Light | Material | Iron And Aluminium |
|---|---|---|---|
| Frequency Range | 50-60Hz | Lamp Efficiency | ＞92% |
| Color | White,Yellow,Red,Blue,Green,Golden And Black | Installing Size | Φ61mm |
| Central Illumination | 47lux(10m) | Lumen | 150lm/w |
| Voltage | 100-265V | IP | 65 |
| PF | 0.9 | Working Life | 80000HRS |
| Power | 150W | Service | Customization |
| High Light | 30w all in one solar street light,100w solar panel street light,all in one solar street light 100-265V |
||
Product Description
led all in one solar street light parameters
Integrated solar LED street light, also known as solar LED integrated light, is a combination of high-efficiency solar panels, 6-8 years long-life lithium batteries, high-luminous-efficiency LEDs and intelligent controllers, anti-theft installation brackets. Also called all in one solar LED street light or integrated solar LED garden light. The integrated solar street lamp is converted into electricity by solar panels and then recharges the lithium batteries in the integrated solar street lamp. During the day, even on cloudy days, the solar generator (solar panel) collects the energy needed for storage and automatically supplies LED lights at night, enabling night lighting.
| Parameter | BCT-OLF-80W | BCT-OLF-100W |
| Solar panel (single crystal) | 80W | 100W |
| Lithium iron phosphate battery (built-in) | 3.2V/100(±5)Ah | 3.2V/100(±5)Ah |
| Main light source (main light source) | 6000lm | 7000lm |
| Light source (secondary light source) | 1000lm | |
| Lighting time | ||
| Installation height | 8-10m | 8-10m |
| Installation distance | 35-45m | 35-45m |
| CCT | 3000-6500K | 3000-6500K |
| Pole diameter | 60-65mm | 60-65mm |
| Solar panel charging time(Under strong sunlight) | 8hours | 8hours |
| Solar panel charging time(rain) | 3-5days | 3-5days |
| Day working time | ≥12hours | ≥12hours |
| Storage temperature | 0-55℃ | 0-55℃ |
| Working temperature | ≤90RH% | ≤90RH% |
| Waterproof grade | IP65 | IP65 |
| Product size | 1047*390*273mm | 1417*390*273mm |
1.Solar Panel:mono or poly-crystalline,20years life.
2.Battery:maintenance-free lead-acid or gel battery,over charge and over discharge protection,7-8years life.
3.Controller:MPPT charging mode,switch mode,switch on/off by light and time,5years life.
4.LED lamp:imported LED chip,high efficiency,more than 80000hours life.
5.Pole:zinc-plated steel pole and painting color of your choice,with the whole kit of stainless steel fasteners,20 years life.
6.Working Hours:10-12hours/night,normal lighting 360days/year.
7.Environmental Temperature:-30℃~+60℃
8.Wind Resistance:more than 150km/h
9.Dustproof andwaterproof.
10.Height:6m-12m.
(Custom-made specific requirements!)
