40w All In One Integrated Solar Street Light 8m 9m 10m 11m 12m 60 Wp

Place of Origin CHINA
Brand Name Coursertech
Certification 202130742917.X
Model Number JMGD-I009
Minimum Order Quantity 100
Price 120USD
Packaging Details CARTON
Delivery Time 30 work days
Payment Terms T/T
Supply Ability 20000 sets a month
Product Details
Material Iron And Aluminium Frequency Range 50-60Hz
Lamp Efficiency >92% Color Customization ( White,Yellow,Red,Blue,Green )
Installing Size Φ61mm Central Illumination 47lux(10m)
Lumen 160lm/w Voltage 100-265V
IP 65 PF 0.9
Working Life 80000HRS Power 150W
Pole Height Customization Product Size 1417*390*273mm
High Light

60 wp all in one solar 40w street light

,

40w All In One Integrated Solar Street Light

,

integrated solar street light 40w

Leave a Message
Product Description

Solar Integrated Street Light 8m 9m 10m 11m 12m

In comparison with all in one design, the Separated Solar Street Light has a unique benefit due to its separated design of solar panel and LED lights. The size of solar panel can be expanded for higher watts / power output by adding extra panels. The separated solar street light battery capacity decides how big solar cell can be.

Solar energy street light uses high efficiency mono or poly crystal solar panel,maintenance-free acid or gel battery,
advanced sufficient charge and discharge controller,reliable,high efficiency,convenient in stallment,
no need to lay down electric wire,no need to use AC grid to pay electrical bill,
photosensitive control,safe,reliable,energy conservation,economy,environmental protection,practical,long life(solar panel to be possible to use 15-20years,battery to be possible to use for 5-8years),
which will be a lanterns beauty of outdoors illumination development direction in the future.



1.Solar Panel:mono or poly-crystalline,20years life.
2.Battery:maintenance-free lead-acid or gel battery,over charge and over discharge protection,7-8years life.
3.Controller:MPPT charging mode,switch mode,switch on/off by light and time,5years life.
4.LED lamp:imported LED chip,high efficiency,more than 80000hours life.
5.Pole:zinc-plated steel pole and painting color of your choice,with the whole kit of stainless steel fasteners,20 years life.
6.Working Hours:10-12hours/night,normal lighting 360days/year.
7.Environmental Temperature:-30℃~+60℃
8.Wind Resistance:more than 150km/h
9.Dustproof andwaterproof.
10.Height:6m-12m.
(Custom-made specific requirements!)





Parameter BCT-OLF-80W BCT-OLF-100W
Solar panel (single crystal) 80W 100W
Lithium iron phosphate battery (built-in) 3.2V/100(±5)Ah 3.2V/100(±5)Ah
Main light source (main light source) 6000lm 7000lm
Light source (secondary light source)   1000lm
Lighting time
Installation height 8-10m 8-10m
Installation distance 35-45m 35-45m
CCT 3000-6500K 3000-6500K
Pole diameter 60-65mm 60-65mm
Solar panel charging time(Under strong sunlight) 8hours 8hours
Solar panel charging time(rain) 3-5days 3-5days
Day working time ≥12hours ≥12hours
Storage temperature 0-55℃ 0-55℃
Working temperature ≤90RH% ≤90RH%
Waterproof grade IP65 IP65
Product size 1047*390*273mm 1417*390*273mm
