30w-240w solar light led Street Light Waterproof High Lumen Aluminum Pcb 150lm/w high efficiency

Place of Origin CHINA
Brand Name Coursertech
Model Number JMHX-004
Minimum Order Quantity 100
Price 60USD
Packaging Details CARTON
Delivery Time 30 work days
Payment Terms T/T, L/C, Western Union, MoneyGram
Supply Ability 20000 sets a month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product Name 004 Led Street Lights Watt 30W,60W,120W,160W,240W
CCT 3000-4500K Lumen 140lm/w
Application Scenarios Yards, Driveways, Streets, Highways Installing Size Φ61mm
Voltage 100-265V Power 30-250W
Life Time 80000HRS
High Light

30w street light waterproof


aluminum pcb street light waterproof


240w waterproof street light

Leave a Message
Product Description

Minimum 30w Maximum 240w Classic Ip65 Led Street Lights Applied To The Street


Energy saving is the energy saved under the same average illuminance, the average illuminance can not only be the ground average illuminance! The light intensity of the space has a good prediction for the vehicles coming in the distance, so as to prevent traffic accidents. But the LED street lamps installed in China all sacrifice illumination to achieve energy saving.

Heat dissipation of LED street lamps

Street lamps are used outdoors, to be waterproof and dustproof, so the lamps must be sealed, sealed after the temperature of the water vapor in the lamps in extreme climate conditions is more than 100 degrees, LED in such a high temperature environment continuous work, LED street lamps if the heat dissipation is not done, the lamps are very easy to bad or serious light failure. The heat dissipation problem of domestic high-power LED street lamps has not been completely solved, and the subsequent maintenance cost of the products will inevitably increase.

The penetration ability of LED lights

On rainy and foggy days, LED lighting line is not strong enough to wear fog.

It is easy to attract mosquitoes outdoors

Because mosquitoes are particularly fond of some wavelengths of LED light, there are moths flurping the flame, which will affect its light efficiency.

To sum up: LED, as a new light source, has irreplaceable advantages in replacing incandescent lamps and fluorescent lamps, but there are still some problems in the use of high-power LED street lamps. Radical and comprehensive replacement of LED street lamps (especially on main roads) may cause sequelae. If extreme weather occurs, a large number of lights may be broken or severe light failure, affecting road safety.



No Parameter
/Item No
1 Rated Power 80-150w 200-250w
2 LED Chip 5W/pc 5W/pc
3 LED Quantity 88 132
4 CCT 3500K-4500K 3500K-4500K
5 Voltage AC100-265V AC100-265V
6 Frequrncy Range 50-60Hz 50-60Hz
7 Power factor 0.975 0.975
8 Lumen 150lm/w 150lm/w
9 Total lumen 12000lm 30000lm
10 IP IP65 IP65
11 Working life >80000HRS >80000HRS
12 Environment Temperature -30℃to+65℃ -30℃to+65℃
13 Light Body material Aluminium Aluminium
14 Pole Height 10-12m 12m
15 Installing Size Φ61mm Φ61mm
16 Products Size 885*361*166mm 1053*379*174mm
17 Packing Size 900*380*190mm 1070*400*180mm
18 Net Weight 15KG 24KG
19 Gross Weight 16.5KG 26KG


Parameter Informations JMJX-30 JMJX-60 JMJX-90 JMJX-120 JMJX-150
Rated Power 30W 60W 90W 120W 150W
LED Chip 3W/pc 3W/pc 3W/pc 3W/pc 3W/pc
LED Quantity 24 48 72 96 120
Color Temperature 4500-5500K 4500-5500K 4500-5500K 4500-5500K 4500-5500K
Input Voltage AC100-260V AC100-260V AC100-260V AC100-260V AC100-260V
Frequency Range 50-60Hz 50-60Hz 50-60Hz 50-60Hz 50-60Hz
Power Factor >0.97 >0.97 >0.97 >0.97 >0.97
LED Luminous Efficiency 140lm/w 140lm/w 140lm/w 140lm/w 140lm/w
Lamp's Efficiency
>92% >92% >92% >92% >92%
IP Grade IP65 IP65 IP65 IP65 IP65
Working life >80000HRS >80000HRS >80000HRS >80000HRS >80000HRS
Environment Temperature -30℃to+65℃ -30℃to+65℃ -30℃to+65℃ -30℃to+65℃ -30℃to+65℃
Light Body material Aluminium Aluminium Aluminium Aluminium Aluminium
Pole Height 6m 7m 9m 10m 12m
Central Illumination 40lux(6m) 55lux(7m) 48lux(9m) 47lux(10m) 40lux(12m)
Pole Distance 25M 35M 40M 45M 50M
Installing Size Φ61mm Φ61mm Φ61mm Φ61mm Φ61mm
Products Size 520*380*120mm 600*380*120mm 720*380*120mm 840*380*120mm 960*380*120mm
Packing Size 580*445*185mm 660*445*185mm 780*445*185mm 900*445*185mm 1020*445*185mm
Net Weight 8KG 10KG 12KG 14KG 16KG
Gross Weight 10KG 12KG 14KG 16KG 18KG
