160lm/W Waterproof LED Street Light All In One Led Street Light 150w 30w 35 W IP65
Material | Iron And Aluminium | Color | Customizable |
---|---|---|---|
Lumen | 160lm/w | Voltage | 100-240V |
IP Grade | IP65 | Working Life | >80000HRS |
CCT | 3000-4500K | Central Illumination | 47lux(10m) |
Pole Height | 10m / Customizable | Product Size | 720*380*120mm |
High Light | 160lm/W 35 w led street light Coursertech,160lm/W 30w street light Coursertech,160lm/W all in one led street light 150w Coursertech |
LED Street Light Lens And Lamp Shade Integrated Design Outdoor Lighting IP65
The LED street lamp has a unique secondary optical design, which irradiates the light from the LED street lamp to the desired lighting area, further improving the lighting efficiency to achieve the purpose of energy saving.
Its own characteristics - light unidirectional, no light diffuse, to ensure the efficiency of lighting.
The biggest feature of LEDs for lighting is the function of directional emission of light, because power LEDs are almost all equipped with reflectors, and the efficiency of such reflectors is significantly higher than that of lamps and lanterns. In addition, the efficiency of the self-reflector has been included in the light efficiency detection of the LED. Road lamps using LEDs should make use of the directional light emission characteristics of LEDs as much as possible, so that each LED in the road lamps directly emits light to each area of the illuminated road, and then uses the auxiliary light distribution of the lamp reflector to achieve A very reasonable comprehensive light distribution of road lamps. In the actual design of road lighting fixtures, it is possible to fix each LED on the fixture with a spherical joint on the premise of basically setting the radiation direction of each LED. When the fixtures are used for different heights and illumination widths When , the irradiating direction of each LED can achieve satisfactory results by adjusting the spherical gimbal.
Parameter Informations | JMJX-30 | JMJX-60 | JMJX-90 | JMJX-120 | JMJX-150 |
Rated Power | 30W | 60W | 90W | 120W | 150W |
LED Chip | 3W/pc | 3W/pc | 3W/pc | 3W/pc | 3W/pc |
LED Quantity | 24 | 48 | 72 | 96 | 120 |
Color Temperature | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K | 4500-5500K |
Input Voltage | AC100-260V | AC100-260V | AC100-260V | AC100-260V | AC100-260V |
Frequency Range | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz | 50-60Hz |
Power Factor | >0.97 | >0.97 | >0.97 | >0.97 | >0.97 |
LED Luminous Efficiency | 140lm/w | 140lm/w | 140lm/w | 140lm/w | 140lm/w |
(%) Lamp's Efficiency | >92% | >92% | >92% | >92% | >92% |
IP Grade | IP65 | IP65 | IP65 | IP65 | IP65 |
Working life | >80000HRS | >80000HRS | >80000HRS | >80000HRS | >80000HRS |
Environment Temperature | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ | -30℃to+65℃ |
Light Body material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
Pole Height | 6m | 7m | 9m | 10m | 12m |
Central Illumination | 40lux(6m) | 55lux(7m) | 48lux(9m) | 47lux(10m) | 40lux(12m) |
Pole Distance | 25M | 35M | 40M | 45M | 50M |
Installing Size | Φ61mm | Φ61mm | Φ61mm | Φ61mm | Φ61mm |
Products Size | 520*380*120mm | 600*380*120mm | 720*380*120mm | 840*380*120mm | 960*380*120mm |
Packing Size | 580*445*185mm | 660*445*185mm | 780*445*185mm | 900*445*185mm | 1020*445*185mm |
Net Weight | 8KG | 10KG | 12KG | 14KG | 16KG |
Gross Weight | 10KG | 12KG | 14KG | 16KG | 18KG |
